Image Sensor |
1/4″ CMOS Image Sensor |
|
Resolution |
720P@25/30fps |
|
Effective Pixels |
1280(H)*720(V) |
|
Video Standard |
PAL/NTSC |
|
Synchronization |
Internal |
|
Day & Night mode |
External Control(default)/Auto /(B/W )/Color(OSD Switch) |
|
WDR |
Digital WDR |
|
Min. Illumination |
0.1Lux@(F1.2,AGC ON),0LUX with IR |
|
S/N Ratio |
≥46dB(AGC OFF) |
|
Electronic Shutter |
AUTO/ 1/50(1/60)-1/100,000sec |
|
White Balance |
ATW1/USER/PUSH |
|
AGC |
LOW / MID / HIGH(default) |
|
BLC |
Default OFF ( AREA adjustable) |
|
DNR |
0-100 Adjustable |
|
Language |
English/ Simplified Chinese/Japanese |
|
OSD Menu |
OSD Menu,Control up the coaxial cable (UTC) |
|
Video Output |
AHD-720P |
|
Sens-up |
N/A |
|
IR Distance |
15M |
|
IR Led |
Invisible IR Leds |
|
Other |
Defog, Motion Detection, Privacy Mask, Mirror, Flip |
|
LENS |
|
|
Focal Length |
3.7mm pinhole Lens |
|
Lens Mount |
M12 |
|
General |
|
|
Type |
Hidden Camera |
|
Weather Proof |
N/A |
|
Power Supply |
12 V DC±10% |
|
Power Consumption |
3.6W(IR ON) |
|
Operating Temp. |
-20 °C to +50 °C (- 14 °F to 122 °F ) |
|
Storage Temp. |
-40 °C to +60 °C ( -40 °F to 140 °F ) |
Indoor wifi camera is after connecting to the wifi router through wifi, you need to set the ssid and encryption method and password of the wifi router connected to the camera, and the router may also need to set the mapping function of the IP corresponding to the camera before it can be accessed by the external network. It is understandable. It is an internal computer with a wireless network card.
The indoor wifi camera can be monitored remotely, generally there are two ways:
- Some wifi cameras have their own cloud service. General steps:
- Set the network parameters of the camera to connect to the Internet through a router.
- Registering for cloud service, setting the camera is not associated.
- In the case of Internet, you can log in to the cloud service to remotely monitor.
- Without cloud services, you need to directly access the camera through the public IP. This method requires the network to have an exclusive public IP, which cannot be implemented in some broadband networks.
