Thermal camera
|
||
|
Detector
|
Uncooled microbolometer focal array (Vox)
|
|
|
Valid pixel
|
640×512
|
|
|
Spectrum range
|
8～14μm
|
|
|
NETD
|
≤60mK@F1.0,300K
|
|
|
Focal length
|
50 mm (25/35 optional) athermalization
|
|
|
FOV
|
12.4°×9.9°
|
|
|
IFOV
|
0.34mrad
|
|
|
Frame rate
|
50Hz
|
|
|
Image process
|
4× digital zoom, pseudo color
|
|
|
Video format
|
PAL
|
|
|
Focus
|
manual focus
|
|
|
Polarity
|
Black/White-Hot
|
|
|
Control interface
|
RS485，support PELCO-D/PELCO-P
|
|
|
Pseudo color
|
Support，9 kinds colors（optional）
|
|
|
Visible camera
|
||
|
Resolution
|
1920（H）×1080（V）
|
|
|
Sensor
|
1/2.8 ” CMOS, 2.13M
|
|
|
Lens
|
F=4.3mm-129mm，30x optical zoom
|
|
|
F value
|
F1.6~4.4
|
|
|
Focus
|
Auto
|
|
|
IRIS
|
Auto
|
|
|
Working distance
|
||
|
Thermal detection
|
1400m
|
4000m
|
|
Thermal recognition
|
350m
|
1000m
|
|
Thermal identification
|
170m
|
500m
|
|
Visible light camera
|
1000m
|
|
|
Target size
|
Human（1.8m×0.5m） Vehicle（2.3m×2.3m）
|
|
|
Note
|
||
|
The working distance varies depending on the settings of the camera, environmental conditions, operational experience, monitor or display. The above-mentioned working distance is data when the target temperature difference is 2 ° C, the atmospheric attenuation coefficient is 0.85/km, and the probability is 50%.
|
||
The main type of PTZ camera
Ball type PTZ camera
The main components include integrated camera, high-speed stepper motor pan/tilt, embedded solution
Electronic devices such as the encoder board are built in a dome camera shield.
Advantages: easy installation, good protection, strong climate adaptability.
PTZ decoder camera
That is, the mechanical components of the system are external. PTZ, decoder and camera can also be installed and combined independently.
Advantages: strong maintenance, low cost, large monitoring angle, wiper can be installed.
