Camera Module
|
|
|
Image Sensor
|
1/1.8″ progressive scan CMOS
|
|
Min. Illumination
|
Color: 0.0005 Lux @ (F1.0, AGC ON); 0 Lux with white light
|
|
Shutter Speed
|
1/1 to 1/30,000 s
|
|
Day & Night
|
24/7 colorful imaging
|
|
Day/Night Switch
|
day, night, auto, scheduled-switch
|
|
BLC
|
yes
|
|
WDR
|
120 dB WDR
|
|
HLC
|
yes
|
|
3D DNR
|
yes
|
|
Defog
|
yes
|
|
EIS
|
yes
|
|
Regional Exposure
|
yes
|
|
Image Settings
|
saturation, brightness, contrast, sharpness
|
|
Image Parameters Switch
|
yes
|
|
White Balance
|
Locked WB/Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
|
|
Digital Zoom
|
16 ×
|
|
Privacy Mask
|
up to 24 masks (8 masks for each scene)
|
|
SNR
|
＞52 dB
|
|
General Function
|
mirror, password protection, watermark, IP address filter
|
|
Lens
|
|
|
Focal Length
|
4 mm
|
|
FOV
|
Horizontal field of view: 88.7°
Vertical field of view: 46.5° Diagonal field of view: 105.0° |
|
Aperture
|
F1.0
|
|
PTZ
|
|
|
Movement Range (Pan)
|
350°
|
|
Movement Range (Tilt)
|
0° to 90°
|
|
Pan Speed
|
pan speed: configurable from 0.1° to 60°/s; preset speed: 60°/s
|
|
Tilt Speed
|
tilt speed: configurable from 0.1° to 50°/s, preset speed 50°/s
|
|
Proportional Zoom
|
yes
|
|
Presets
|
300
|
|
Power-off Memory
|
yes
|
|
Park Action
|
preset, patrol scan
|
|
3D Positioning
|
yes
|
|
PTZ Status Display
|
yes
|
|
Preset Freezing
|
yes
|
|
Scheduled Task
|
preset, patrol scan, dome reboot, dome adjust, aux output
|
|
Video
|
|
|
Max. Resolution
|
2560 × 1440
|
|
Stream Type
|
main stream, sub-stream, third stream
|
|
Main Stream
|
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720);
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) |
|
Sub-Stream
|
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288);
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240) |
|
Third Stream
|
50Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288);
60Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
|
Video Compression
|
H.265, H.264, MJPEG
|
|
SVC
|
yes
|
|
ROI
|
yes
|
|
Audio
|
|
|
Audio Compression
|
G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, AAC, PCM
|
|
Environment Noise Filtering
|
yes
|
|
Smart Features
|
|
|
Face Capture
|
yes
|
|
Basic Event
|
motion detection, alarm input, alarm output, video tampering alarm, exception
|
|
Smart Event
|
intrusion detection, line crossing detection, region entrance detection, region exiting
detection, unattended baggage detection, object removal detection, audio exception detection |
|
Smart Record
|
ANR, Dual-VCA
|
|
Alarm Linkage
|
preset, memory card video recording, alarm output, sending email, notify surveillance center, upload to FTP, audile warning, white
light flashing |
|
Smart Encoding
|
H.265+, H.264+, low bit rate, ROI, SVC
|
|
Warning and Alert
|
white light and audible warning
|
|
Network
|
|
|
Network Storage
|
NAS (NFS, SMB/ CIFS)
|
|
Protocols
|
IPv4/IPv6, HTTP, HTTPS, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
|
|
API
|
ISAPI, Hikvision SDK, Hik-Connect, Open Network Video Interface (Profile S, Profile G, Profile T), ISUP
|
|
Simultaneous Live View
|
Up to 20 channels
|
|
User/Host
|
Up to 32 users. 3 levels: Administrator, Operator and User
|
|
Security Measures
|
Authenticated username and password, MAC address binding, HTTPS encryption, IP address filter
|
|
Web Browser
|
IE 10+, Chrome 57+, Firefox 52+, Safari 12+
|
|
Wi-Fi
|
|
|
Wi-Fi Protocols
|
IEEE802.11b, 802.11g, 802.11n
|
|
Frequency Range
|
2.4 GHz -2.4835 GHz
|
|
Channel Bandwidth
|
20/40 MHz
|
|
Modulation
|
802.11b: CCK, DQPSK, DBPSK
802.11g: OFDM/64-QAM, 16-QAM, QPSK, BPSK 802.11n: OFDM/64-QAM, 16-QAM, QPSK, BPSK |
|
Encryption Mode
|
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
|
|
Transfer Rates
|
11b: 11 Mbps, 11g: 54 Mbps, 11n: up to 150 Mbps
|
|
Wireless Range
|
Up to 50 m
|
|
Interface
|
|
|
Power Output
|
12 VDC; < 60 mA
|
|
Communication Interface
|
1 RJ45 10 M/100 M Ethernet interface; PoE (802.3at)
|
|
On-board Storage
|
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 512 GB
|
|
Alarm Input
|
1 alarm input
|
|
Alarm Output
|
1 alarm output
|
|
Audio Input
|
1 audio input, 2.0 to 2.4Vp-p, 1k Ohm ± 10%
|
|
Audio Output
|
1 built-in speaker, 1 audio output, line level, impedance: 600 Ω
|
|
RS-485
|
Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive
|
|
Illuminator
|
|
|
Supplement Light Type
|
White Light
|
|
Supplement Light Range
|
30 m
|
|
General
|
|
|
Power
|
12 VDC, 3.33 A & PoE (802.3at), 42.5 to 57 VDC, 0.6 A
Max. 16 W (including max. 4 W for white light) |
|
Operating Conditions
|
humidity: ≤ 90%,temperature: -30°C to 65°C (-22°F to 149°F)
|
|
Reset
|
yes
|
|
Demist
|
yes
|
|
Dimensions
|
179.3 mm × 120 mm × 182 mm (7.06″ × 4.72″ × 7.71″)
|
|
Weight
|
Approx. 1.125 kg (2.48 lb.)
|
|
Approval
|
|
|
Protection
|
IP66; 6000 V Lightning Protection, Surge Protection and Voltage Transient Protection
|
The abbreviation of Pan/Tilt/Zoom, the concept of security monitoring equipment, represents the omni-directional (left and right/up and down) movement of the pan/tilt and the zoom and zoom control of the lens. This word is usually mentioned, and it can be easily understood as PTZ control.
In the scene range monitored by the camera, when a moving target appears, the user can manually lock it (for example, by clicking the mouse to lock the target) or the preset position automatically triggers and locks a moving target to trigger the PTZ camera to perform autonomous and automatic PTZ tracking. And automatically control the PTZ camera’s pan-tilt to rotate in all directions, and perform visual-oriented automatic tracking of the locked moving target to ensure that the tracking target continues to appear in the center of the lens. The automatic PTZ tracking module makes up for the shortcomings of the narrow view of the fixed camera monitoring, and is a necessary function for a complete security monitoring system.
